EYE PBL2410

Specifications

PBL2410 10AMP

Product Details

The PBL2410 10 Amp weatherproof CdS PE Cells are compact and ready to mount in an exterior environment. The leads are colour coded in the standard colours (Red-Active, Black-Neutral, White-Load) to simplify the installation and correction. The cell is supplied complete with its own suitable pole or wall mount.

Specifications

Code                            101010

Type                            CdS

Rating                         10 Amps

Normal input             240V ±10%

Operational level        ON’ 10-80 Lux OFF’ <400 Lux

Construction              Acrylic resin covered with Polystyrene body, Steel Mounting Bracket

Weatherproof             Yes

Dimension                  76mm (H) 64mm offset from wall

Measurements
