FLUKE 177 LIGHT
MULTIMETER DIGITAL + BACKLIGHT
Reviews
Specifications
Digital Multimeters
Extended specifications
Accuracy is specified for 1 year after calibration, at operating temperatures of 18 °C to 28 °C, with relative humidity of 0 % to 90 %.
| Maximum voltage between any | 600 V |
| terminal and earth ground | |
| Surge protection | 6 kV peak per IEC 61010-1 600 V CAT III, Pollution Degree 2 |
| W Fuse for A input | 11 A, 1000 V FAST 17 kA Fuse (Fluke PN 803293) |
| Display | Digital: 6,000 counts, updates 4/sec; Bar Graph: 33 segments, updates 32/sec |
| Temperature | Operating: -10 °C to +50 °C; Storage: -40 °C to +60 °C |
| Humidity | 0 % to 90 % to 35 °C; 75 % to 40 °C; 45 % to 50 °C |
| Temperature coefficient | 0.1 x (specified accuracy/°C) (< 18 °C or > 28 °C) |
| Operating altitude | 2,000 meters |
| Battery | 9 Volt Alkaline, NEDA 1604A/IEC 6LR61 |
| Battery life | Alkaline: 400 hours typical, without backlight |
| Safety compliances | ANSI/ISA 82.02.01 (61010-1) 2004, CAN/CSA C22.2 No 61010-1-04, UL 6101B (2003) and IEC/EN |
| 61010-1 2nd Edition for measurement Category III, 600 V, Pollution Degree 2, EMC EN61326-1 | |
| Certifications | UL, CSA, TUV, N10140 , VDE |
| IP rating (dust and water protection) | IP42 |
