NAN XSD240CLVNB 500M
CABLE CIRC 1C 240mm BK XLPE
Reviews
Specifications
XLPE/PVC SDI (Cu)
| Single Core, Copper Conductors, 0.6/1kV X-90 XLPE insulated, PVC Sheathed to AS/NZS 5000.1 | ||||||
| Product Code | Nominal Conductor type | main conductor type | Nominal insulator thickness | Nominal sheath thickness | approx. mass | |
| mm² | mm | mm | kg/100m | |||
| Copper Conductor | ||||||
| XSD016CLVNB | 16 | Stranded Cu | 0.8 | 9.4 | 21.5 | |
| XSD025CLVNB | 25 | Compacted Cu | 0.9 | 10.5 | 30.7 | |
| XSD035CLVNB | 35 | Compacted Cu | 0 | 11.5 | 40.7 | |
| XSD050CLVNB | 50 | Compacted Cu | 1.0 | 12.9 | 52.7 | |
| XSD070CLVNB | 70 | Compacted Cu | 1.1 | 14.9 | 73.5 | |
| XSD095CLVNB | 95 | Compacted Cu | 1.1 | 16.7 | 99.3 | |
| XSD0120CLVNB | 120 | Compacted Cu | 1.2 | 18.4 | 123 | |
| XSD0150CLVNB | 150 | Compacted Cu | 1.4 | 20.5 | 152 | |
| XSD0185CLVNB | 185 | Compacted Cu | 1.6 | 22.7 | 188 | |
| XSD0240CLVNB | 140 | Compacted Cu | 1.7 | 25.3 | 244 | |
| XSD0300CLVNB | 300 | Compacted Cu | 1.7 | 27.8 | 303 | |
| XSD0400CLVNB | 400 | Compacted Cu | 2.0 | 31.3 | 386 | |
| XSD0500CLVNB | 500 | Compacted Cu | 2.2 | 35.0 | 491 | |
| XSD0630CLVNB | 630 | Compacted Cu | 2.4 | 39.2 | 632 | |
