SUNTREE
SURGE PROTECTION DC 2P 20-40kA
Reviews
Specifications
Detailed Product Description
| Product Name: | Surge Protection Device | Color: | Red/Yellow |
|---|---|---|---|
| Rated Voltage: | DC 500V 800V | Max Discharge Current Imax: | 20kA;40kA |
| Pole: | 2Pole | Protection Grade: | IP20 |
| Certificate: | CE TUV ROHS | Indicated: | Normal:Green ; Abnormal:Red |
| Installation: | TH35-7.5 DIN Rail | Gurantee Period: | 2 Years |
| Port: | Ningbo/shanghai | ||
| High Light: |
CE 2P 500V DC Surge Protector, CE 2P 500V Surge Protection Device, 40KA DC Surge Protector |
||
CE Approved Surge Protection Device 2P DC 500V SPD 20-40KA Surge Protector
Product Description
1. SUP2-PV Series SPD Protect DC Surge Protector Solar, protect against lightning surge voltage in solar system (photovoltaic power supply system).
2. These units must be installed in parallel on the DC networks to be protected and provide common and different modes protection. Its installed location are recommended at both ends of the DC power supply line (soalr panel side and inverter/converter side), ely if the line routing is external and long.
3. High energy MOVs equipped with specificthermal disconnectors and related failure indicators.
Product Parameters
| Type | SUP2-PV | ||
| Pole | 2P | 2P | |
| Uoc max (V DC) | 500 | 800 | |
| Uc (V DC) | 500 | 800 | |
| ln(8/20)us(kA) | 20 | 20 | |
| lmax(8/20)us(kA) | 40 | 40 | |
| Up (kV) | 2 | 3.8 | |
| Maximum working voltage | 250VAC/30VDC | ||
| Maximum working current | 1A(250VAC) | ||
| Wiring capacity | Hard wire | 4-25 | |
| Flexible wire | 4-16 | ||
| Striping length | 10 | ||
| Terminal screwa | M5 | ||
| Torque(Nm) | Main circuit | 3.5 | |
| Remote singal control | 0.25 | ||
| Protection class | All profile | IP40 | |
| Connection port | IP20 | ||
| Installation environment | No obvious shock and cibration | ||
