SUNTREE SL7-63-6A
CIRCUIT BREAKER DC 2P 6A 500V
Reviews
Specifications
Detailed Product Description
| Type: | Mini | Poles Number: | 2P |
|---|---|---|---|
| Product Name: | Single Phase Motor Protection Circuit Breaker | DC Voltage: | DC550V,DC800V |
| Amps: | 6A,10A,16A,32A,40A,60A,63A Etc | Tripping Curve(B/C): | 3-5In/5-10In |
| Mounting: | 35mm Din Rail Breaker | Breaking Capacity: | 4.5ka/6kA |
| Standard: | IEC60947-2 | Shell Color: | White |
| Guarantee Period: | 2 Years | Port: | Ningbo/shanghai |
| Highlight: |
63amp Motor Protection Circuit Breaker, Suntree 2Pole MCB, SL7-63 Motor Protection Circuit Breaker |
||
Suntree SL7-63 Single Phase Motor Protection Circuit Breaker MCB 2 Pole 6-63amp
Product Description
1. Specialised MCB for DC applications
2. Rating 6A, 10A, 16A, 20A, 25A, 32A, 40A, 50A, 63A
3. Type B and C tripping characteristics (details available on request)
4. 4.5 / 6kA short circuit capacity (IEC60947-2)
5. 2P 550V / 800V , 4P 1000V / 1200V
6. Current limiting operation under fault conditions
7. 18mm modular width per pole
8. IP20 finger proof terminals
9. Safety terminals ensure that incorrect connection is not possible
10. Terminal capacity up to 35mm
11. High torque terminals up to 4.5Nm
12. Circuit indicator window allowing clear labeling of circuits
13. Suitable for DIN rail mounting in OEM / panel builder enclosures
14. Suitable for installation in consumer units, design units and MCB distribution boards
15. Toggle is padlockable in “ON” or “OFF” position
16. Wide range of multi-functional accessories
2. Rating 6A, 10A, 16A, 20A, 25A, 32A, 40A, 50A, 63A
3. Type B and C tripping characteristics (details available on request)
4. 4.5 / 6kA short circuit capacity (IEC60947-2)
5. 2P 550V / 800V , 4P 1000V / 1200V
6. Current limiting operation under fault conditions
7. 18mm modular width per pole
8. IP20 finger proof terminals
9. Safety terminals ensure that incorrect connection is not possible
10. Terminal capacity up to 35mm
11. High torque terminals up to 4.5Nm
12. Circuit indicator window allowing clear labeling of circuits
13. Suitable for DIN rail mounting in OEM / panel builder enclosures
14. Suitable for installation in consumer units, design units and MCB distribution boards
15. Toggle is padlockable in “ON” or “OFF” position
16. Wide range of multi-functional accessories
Product Parameters
| Item | DC Mini Circuit Breaker | |||
| Code | SL7-63 | |||
| Pole | 2P | 2P | 4P | 4P |
| Voltage | DC 550V | DC 800V | DC 1000V | DC 1200V |
| Current | 6A/10A/16A/20A/32A/40A/50A/63A | |||
| Standard | IEC/EN60947 | |||
| Breaking Capacity | 4.5KA/6KA/10KA | |||
| Characteristic Curve | B/C/D | |||
| Working Temperature | -5℃ to 40℃ | |||
| Protection Degree | IP20 | |||
| Electrical life | More than 8000 times | |||
| Mechanical life | More than 2000 times | |||
| Installation | 35mm Din Rail | |||
| Accessory | YES | |||
| Installation Altitude | <2000M | |||
